Problem with multiple 1-wire busses.

Post by bopitje » Wednesday 27 September 2017 13:13

Hardware: Raspberry Pi 3
OS: Linux version 4.9.35-v7+ (dc4@dc4-XPS13-9333) (gcc version 4.9.3 (crosstool-NG crosstool-ng-1.22.0-88-g8460611) ) #1014 SMP Fri Jun 30 14:47:43 BST 2017
Domoticz branch: stable
Version number: 3.8153
Build hash: 494fff7
Problem: 1-Wire errors with multi busses
Steps already tried: Reboot, deactivate/activate 1-Wire different scrips.
Reproduce: permanent

Recently, I've connected 2 1-wire busses to the raspberry pi, I noticed that when I connected more than 8 divices (DS18S20) on 1-wire network, wrong values were displayed.

sudo leafpad /boot/config.txt
dtoverlay=w1-gpio
dtparam=gpiopin=4
dtoverlay=w1-gpio
dtparam=gpiopin=17

With the command below, all temperature meters are found and read well.

pi@raspberrypi:/sys/bus/w1/devices $ ls
28-0316b4e27fff 28-0416c13bbdff 28-0416c22449ff w1_bus_master1

28-0316b53e49ff 28-0416c2095eff 28-0516b57ee1ff w1_bus_master2
28-0416c10669ff 28-0416c21f15ff 28-0516c01120ff


But unfortunately not with domoticz, which reads only master1 and not both (Master1 & Master2).
I have already tried several tutorials, but without success. Does anyone have an idea how domoticz can show both w1_bus_masters?

bopitje
Posts: 3
Joined: Saturday 12 November 2016 21:59
Target OS: Raspberry Pi
Domoticz version:
Contact:

Re: Problem with multiple 1-wire busses.

Post by bopitje » Wednesday 04 October 2017 21:37

Does anyone have an idea?
With the terminal I can see/ read all the sensors. Unfortunately not with domoticz.
Domoticz only reads master1 and not both (Master1 & Master2).


fantom
Posts: 324
Joined: Thursday 26 March 2015 11:40
Target OS: Raspberry Pi
Domoticz version:
Location: Poland
Contact:

Re: Problem with multiple 1-wire busses.

Post by fantom » Sunday 15 October 2017 18:20

I see, that 1wire searching devices only in w1:
https://github.com/domoticz/domoticz/bl ... l.cpp#L189

Fantom

bopitje
Posts: 3
Joined: Saturday 12 November 2016 21:59
Target OS: Raspberry Pi
Domoticz version:
Contact:

Re: Problem with multiple 1-wire busses.

Post by bopitje » Saturday 21 October 2017 20:06

Does anyone have an idea how to get this together?

zazoo
Posts: 1
Joined: Saturday 15 September 2018 13:24
Target OS: Raspberry Pi
Domoticz version:
Contact:

Re: Problem with multiple 1-wire busses.

Post by zazoo » Saturday 15 September 2018 13:39

Hello,

I see your post is 1 year old, so did you find a solution ?
I have exactly the same issue with my Raspberry (PI 2) running Domoticz: All sensors of both buses are identify at linux prompt. I can read all the temperatures using the "find" instruction :
pi@raspberrypi:/sys/bus/w1/devices $ find /sys/bus/w1/devices/ -name "28-*" -exec cat {}/w1_slave \; | grep "t=" | awk -F "t=" '{print $2/1000}'
21.375
19.625
21.25
19.812
21.812
21.062
24.812

But, it is impossible to have the sensors of both buses under Domoticz.
Only the first declared bus (in /boot/config.txt file) is used by the application software.

Thank a lot in advance if someone have a solution. I think it is very convenient to use multiple buses when number of sensors increase.

fantom
Posts: 324
Joined: Thursday 26 March 2015 11:40
Target OS: Raspberry Pi
Domoticz version:
Location: Poland
Contact:

Re: Problem with multiple 1-wire busses.

Post by fantom » Sunday 16 September 2018 11:05

1wire by kernel uses only w1
https://github.com/domoticz/domoticz/bl ... Kernel.cpp
You must rewrite this code, if You want use more buses.

Fantom
I may try change this, but I don't use kernel.
